Foam Balers

Automatic foam baler APK-SS

Sophisticated technology – fully automated

This fully automatic channel baling press is specially designed for expanding material likefoam. The effective retaining claw system, the reliable SPS control and our automatic binding system Drillfix ensure a continuous and troublefree operation of the baler.

fully automatic binding system ‘Drillfix’ (horizontal and vertical)
high bale weights up to 300kg
universal application
ideal bale dimensions for container loading

Details

large loading aperture ensures easy handling
specially designed retaining claws keep enough space in the filling chamber and provide a continuous operation
SPS and display for reliable control and monitoring
hydraulic is equipped with a powerful and energy efficient self-regulating pump
reliable and fully automatic binding system ‘Drillfix’ by Austropressen
horizontal and vertical strapping of the bale guarantee maximum safety and high bale weights up to 300kg
high durability and reliability based on our quality standards

Specifications
Model	APK-SS 42	APK-SS 55
Compression force	420 kn	550 kn
Motor	22 kW	45 kW
Compression Time	60 Sec	112 Sec
loading aperture	2400x940 mm	2500x1500 mm
Loading volume	1,5 m³
Bale Size	1000x700 mm	700x700x1200 mm
Bale Length	800-1200 adjustable mm
Bale Weight	250-300 kg	300 kg
Binding	3h+4v	3h+4v
Dimensions lxwxh	9000x4200x3300 mm	17000x6200x2700+1200 mm
Weight	9500 kg	16000 kg
