APS 35/42/55

Horizontal Baling Press APS

Concentrated pressure

Continuously operating horizontal baling press for cardboard and plastic film. Suitable for automatic feeding due to special cutting system. The hydraulically secured ejection door ensures high bale weights and maximum operator safety. Vertical binding with wire.

High level of automation
Remarkable throughput performance
special designed cutting system
High bale weights

Details

special cutting system ensures continuous and automatic feeding
Maximum ease of operation at the touch of a button
Hydraulically secured ejection door ensures maximum safety and high bale weights
Loading apertures and binding slots are protected with safety cages and grids
High level of automation and remarkable throughput performance
Bale length is adjustable due to horizontal binding with wire or plastic strapping tape
in combination with a tipping device the ideal solution for industry and warehouses.
Bale is ejected automatically.
High durability and reliability based on our quality standards.

Specifications
Model	APS 35	APS 42	APS 55
Compression force	350 kn	420 kn	550 kn
Motor	11 \| 15 kW	15 \| 22 kW	22 kW
Compression Time	40 \| 60 Sec	40 \| 60 Sec	70 Sec
specific pressure force	58 N/cm²	56 N/cm²	50 N/cm²
loading aperture	1200x740 mm	1200x940 mm	1400x1040 mm
loading height	1600 mm	1600 mm	1600 mm
Bale size	800x750x1200 mm	1000x750x1200 mm	1100x1000x1200 mm
bale weight	150-300 kg	250-450 kg	500-800 kg
binding	4v	4v	4v
dimensions lxwxh	6400x1300x2500 mm	6400x1500x2500 mm	7600x1600x2700 mm
weight	6200 kg	7200 kg	11000 kg
